Description

LOA 70 m
Beam 16,8 m
Draft 6,1 m
Bollard Pull : 138 tons

Dynamic Positioning of class : DP 2
Free Deck area about 462m² with a deck strength of 7,5 metric tonnes per square meter
Capable of supplies of 1.239m³ Fuel Oils, 389m³ FW and 489m³ Liquid Mud
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 2,2 tons

Built in year 2007
Design is : KCM 70M
Class : China Classification Society
Flag : China
Gross Tonnage of 2.705 and Nett Tonnage of 812

Deadweight : 2.099 metric tonnes

Total 50 berths

Speed : 12 knots
Engines : 2 x Wartsila / Wartsila Finland Oy 8L32, 8.000 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 410 kw, Bowthruster + Sternthruster (2 Bow Thwart. CP thruster 680kw + 1 Stern Thwart. CP thruster 680kw)

Specifications

Engine(s)

2 x 8.000 kw, 750 rpm, Wartsila / Wartsila Finland Oy 8L32,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
