Description

LOA 65,5 m
Beam 16 m
Draft 5,8 m
Bollard Pull : 115 tons

Dynamic Positioning of class : DP 1
Free Deck area about 415m²
Fire Fighting System of type FiFi 1 installed

Built in year 2010
Design is : Armada-8000
Class : China Classification Society
Flag : China
Gross Tonnage of 2.183 and Nett Tonnage of 655

Deadweight : 1.989 metric tonnes

Engines : 2 x Bergens / Rolls-Royce Marine AS B32:40L6P, 6.000 kw, 750 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 620 kw

Specifications

Engine(s)

2 x 6.000 kw, 750 rpm, Bergens / Rolls-Royce Marine AS B32:40L6P,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network

Disclaimer

GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
